AlNiCo permanent magnet High temperature resistant 700C to 850C

Aluminum Nickel FerroCobalt magnets introduction, magnetic property, physical property, temperautre resistance.

Hits :
0
Updatetime :
2023-11-08
Material :
Aluminum Nickel Cobalt
Type :
Permanent
Feature :
High temperature resistance

contact now

description

AlNiCo Magnet is a kind of high-performance synthetic permanent magnet composing of metallic aluminum, nickel, ferrocobalt, and other matallic elements. According to different production modes, it can be divided into 2 types: Casting and Sintering, for casting type, different core size can be produced, magnet energy is high, temperature coefficient for production is low; for sintering typel, generally, it is defined as smaller size, but mechnical strength is higher than casting type.

Features of AlNiCo magnets:
Compact crystallization, high strength, strong resistance to corrosion; composition uniformity, excellent magnet performance; good temperatures stability(Br temperature coefficient is the minimum among all kinds of permanent magnet materials). Maximum service temperature reaches 500 deg. Sintered magnet can be produced to be small volume, complicated shape magnet and build-up magnet.
Because of its temperature condition is excellent(maximum operating temperature can 500 deg), low temperature coefficient, high hardness, strong magnet, and other iron features, it is broadly applied in generator, loudspeaker, measuring instrument, eletro-technical instrument, and other fields.

Grade	MMPA Equivalent	Br	bHc	iHc	(BH)max	Density	Br.Temp	Curie Temp	Remark
Grade	MMPA Equivalent	mT(KGs)	KA/m(kOe)	KA/m(kOe)	KJ/m³(MGOe)	g/cm³	Coefficient %/℃	Tc ℃
FLN8	S.AlNiCo-3	520	40	43	8-10	6.7	-0.02	760	Isotropy
FLN8	S.AlNiCo-3	(5200)	(500)	(540)	(1.0-1.25)	6.7	-0.02	760
FLN12	S.AlNiCo-2	700	40	43	12-14	7	-0.014	810
FLN12	S.AlNiCo-2	(7000)	(500)	(540)	(1.5-1.75)	7	-0.014	810
FLN14		570	76	78	14-16	7.1	-0.02	850
FLN14		(5700)	(950)	(980)	(1.75-2)	7.1	-0.02	850
FLN18	S.AlNiCo-7	600	95	107	18-22	7.2	-0.016	850
FLN18	S.AlNiCo-7	(6000)	(1200)	(1350)	(2.25-2.75)	7.2	-0.016	850
FLN28		1050	46	47	28-33	7.2	-0.016	850	Anisotropy
FLN28		(10500)	(580)	(590)	(3.5-4.15)	7.2	-0.016	850
FLN34	S.AlNiCo-5	1100	50	51	34-38	7.2	-0.02	890
FLN34	S.AlNiCo-5	(11000)	(630)	(640)	(4.3-4.8)	7.2	-0.02	890
FLN28	S.AlNiCo-6	1000	56	57	28-30	7.2	-0.02	850
FLN28	S.AlNiCo-6	(10000)	(700)	(710)	(3.5-3.8)	7.2	-0.02	850
FLN38J		730	151	163	38-40	7.2	-0.02	850
FLN38J		(7300)	(1900)	(2050)	(4.75-5)	7.2	-0.02	850
FLN38	S.AlNiCo-8	800	123	126	38-42	7.2	-0.02	850
FLN38	S.AlNiCo-8	(8000)	(1550)	(1580)	(4.75-5.3)	7.2	-0.02	850
FLN42	S.AlNiCo-8	880	120	122	42-48	7.25	-0.02	850
FLN42	S.AlNiCo-8	(8800)	(1500)	(1530)	(5.3-6)	7.25	-0.02	850

Grade	MMPA Equivalent	Br	bHc	(BH)max	Density	Br.Temp	Curie Temp	Remark
Grade	MMPA Equivalent	mT(KGs)	KA/m(kOe)	KJ/m³(MGOe)	g/cm³	Coefficient %/℃	Tc ℃
LN9	AlNiCo-3	680	30	9	6.9	-0.03	760	Isotropy
LN9		(6800)	(380)	(1.13)	6.9	-0.03	760
LN10		600	40	10.00	6.9	-0.03	760
LN10		(6000)	(500)	(1.20)	6.9	-0.03	760
LNG12	AlNiCo-2	720	45	12.40	7	-0.03	810
LNG12		(7200)	(560)	(1.55)	7	-0.03	810
LN13		700	48	13.00	7	-0.03	810
LN13		(7000)	(600)	(1.60)	7	-0.03	810
LNG34	AlNiCo-5C	1200	48	34.00	7.3	-0.02	860	Anisotropy
LNG34	AlNiCo-5C	(12000)	(600)	(4.30)	7.3	-0.02	860
LNG37	AlNiCo-5	120	48	37.00	7.3	-0.02	860
LNG37		(1200)	(600)	(4.65)	7.3	-0.02	860
LNG40		1250	48	40.00	7.3	-0.02	860
LNG40		(12500)	(600)	(5.00)	7.3	-0.02	860
LNG44	AlNiCo-5DG	1250	52	44.00	7.3	-0.02	860
LNG44	AlNiCo-5DG	(12500)	(650)	(5.50)	7.3	-0.02	860
LNG52	AlNiCo-5~7	1300	58	52.00	7.3	-0.02	860
LNG52	AlNiCo-5~7	(13000)	(700)	(6.50)	7.3	-0.02	860
LNGT28	S.AlNiCo-6	1000	58	28.00	7.3	-0.02	860
LNGT28	S.AlNiCo-6	(10000)	(700)	(6.50)	7.3	-0.02	860
LNGT36J	AlNiCo-8HC	700	140	36.00	7.3	-0.02	860
LNGT36J	AlNiCo-8HC	(7000)	(1750)	(4.50)	7.3	-0.02	860
LNGT32	AlNiCo-8	800	100	32.00	7.3	-0.025	860
LNGT32		(8000)	(1250)	(4.00)	7.3	-0.025	860
LNGT40		800	110	40.00	7.3	-0.025	860
LNGT40		(8000)	(1380)	(5.00)	7.3	-0.025	860
LNGT60	AlNiCo-9	900	110	60.00	7.3	-0.025	860
LNGT60	AlNiCo-9	(9000)	(1380)	(7.50)	7.3	-0.025	860
LNGT72	AlNiCo-8	1050	112	72.00	7.3	-0.025	860
LNGT72		(10500)	(1400)	(9.00)	7.3	-0.025	860
LNGT80		1100	115	80.00	7.3	-0.025	860
LNGT80		(11000)	(1450)	(10.00)	7.3	-0.025	860

Product label	Strong Magnets, Permanent Magnets, Neodymium Magnets
Production Capability	50 Tons per month
Customized Service	Dimension, >200 units Shape, >200 units Package, >1000 boxes Logo, >1000 units
Packing form	50-1000pcs per box, depends on sizes. box size: 15x10x8cm 16 boxes per carton with isolated magnetic sheets. Carton size: 38x26x22cm, 20kg 15x10x8cm, 5kg(smaller)
Shipping method	International Express, Sea freight, Air freight
Lead time	<1000 units, 7-15 days. <10000 units, 15-25 days. <100000 units, 25-30 days.
Accept payment method	L/C, TT
Sample	Available
